Features
- Full Bore/Reduce Bore
- Blow Out Proof Stem
- Low Torque/Antistatic Device
- Spring Loaded Seat/Stem Extension
- Locking Device/Double Block & Bleed/Drain & Vent
- Self Relieving Seat/Double Piston Seat
- Corrosion Resistant Low Friction Bearing
- Emergency Sealant Injection
- Trunnion Mounted Design Stem
- Fire Safe Test Requirement as per API 607 & API 6FA
- Ansi Class / Rating: 150#, 300#, 600#, 900#
- Design Standard: API 6D, BS EN ISO 17292, ASME B16.34
- Testing Standard: API 6D, API 607, API 6FA
- F to F Standard: API6D, ASME B16.10
- End Connection Standard: ASME B16.5, ASME B16.47
- Ends: Flanged End, Butt Weld End, Ring Type Joint
- Operation: Mannual with Gear, Pneumatic, Electric, Gas Over Oil, Gas Powered, Hydraulically Operated, etc
Materials
- Body: A105, LF2, LF6, F304, F316, etc.
- Seat: RPTFE, GFT, CFT, Viton, Peek, Devlon, etc.
